No. Part Name Main Unit Reference
S205 Middle Deck Paper Presence/Absence Sensor Pickup Unit -
S206 Middle Deck Paper Surface Sensor Pickup Unit -
S208 Middle Deck Lifter Upper Limit Sensor Deck Unit -
S210 Middle Deck Relay Paper Sensor Deck Unit -
S211 Middle Deck Lifter Lower Limit Sensor Deck Unit -
S213 Middle Deck Paper Length Detection Sensor 1 Deck Unit -
S214 Middle Deck Paper Length Detection Sensor 2 Deck Unit -
S215 Middle Deck Swing HP Sensor Deck Unit -
S301 Lower Deck Foreign Substance Sensor - -
S302 Lower Deck Open/Close Sensor - -
S303 Lower Deck Pickup Sensor Pickup Unit -
S304 Lower Deck Pull-out Sensor Pickup Unit -
S305 Lower Deck Paper Presence/Absence Sensor Pickup Unit -
S306 Lower Deck Paper Surface Sensor Pickup Unit -
S308 Lower Deck Lifter Upper Limit Sensor Deck Unit -
S310 Lower Deck Relay Paper Sensor Deck Unit -
S311 Lower Deck Lifter Lower Limit Sensor Deck Unit -
S313 Lower Deck Paper Length Detection Sensor 1 Deck Unit -
S314 Lower Deck Paper Length Detection Sensor 2 Deck Unit -
S315 Lower Deck Swing HP Sensor Deck Unit -
S401 Multi Tray Inlet Sensor Through Path Inlet Unit -
S402 Through Path Inlet Sensor Through Path Inlet Unit -
S414 Through Path Front Cover Open/Close Sensor Through Path Unit -
S415 Front Alignment Plate HP Sensor Through Path Unit -
S420 Through Path Double Feeding Sensor (receive) Through Path Inlet Unit -
S421 Through Path Double Feeding Sensor (transmis-
sion)
Through Path Inlet Unit -
S501 Upper Double Feeding Sensor (receive) Feed Unit -
S502 Upper Double Feeding Sensor (transmission) Feed Unit -
S503 Lower Double Feeding Sensor (receive) Feed Unit -
S504 Lower Double Feeding Sensor (transmission) Feed Unit -
S59 Rear Alignment Plate HP Sensor Through Path Unit -
S60 Through Path Outlet Sensor 1 Through Path Outlet Unit -
S61 Through Path Disengagement HP Sensor 2 Through Path Outlet Unit -
S62 Through Path Disengagement HP Sensor 1 Through Path Outlet Unit -
S64 Through Path Outlet Sensor 2 Through Path Outlet Unit -
S65 Connect Deck Inlet Sensor Through Path Inlet Unit -
4. Parts Replacement and Cleaning
67
