S201
S202
S215
S401
S402
S208
S206
S205
S211
S204
S203
S210
S213
S214
S420
S421
S65
S414
S415
S59
S60
S64
S61
S62
S301
S302
S315
S208
S314
S313
S308
S306
S305
S304
S303
S310
S311
No. Part Name Main Unit Reference
S001 Vertical Path Upper Sensor Feed Unit -
S002 Vertical Path Middle Sensor Feed Unit -
S003 Vertical Path Lower Sensor Feed Unit -
S004 Horizontal Path Sensor 1 Feed Unit -
S005 Horizontal Path Sensor 2 Feed Unit -
S006 Deck Left Front Cover Open/Close Sensor - -
S007 Environment Sensor - -
S011 Horizontal Path Disengagement HP Sensor 1 - -
S012 Horizontal Path Disengagement HP Sensor 2 - -
S013 Flapper HP Sensor - -
S101 Upper Deck Foreign Substance Sensor - -
S102 Upper Deck Open/Close Sensor - -
S103 Upper Deck Pickup Sensor Pickup Unit -
S104 Upper Deck Pull-out Sensor Pickup Unit -
S105 Upper Deck Paper Presence/Absence Sensor Pickup Unit -
S106 Upper Deck Paper Surface Sensor Pickup Unit -
S109 Upper Deck Lifter Upper Limit Sensor Deck Unit -
S110 Upper Deck Relay Paper Sensor Deck Unit -
S111 Upper Deck Lifter Lower Limit Sensor Deck Unit -
S112 Upper Deck Paper Length Detection Sensor 1 Deck Unit -
S113 Upper Deck Paper Length Detection Sensor 2 Deck Unit -
S114 Upper Deck Swing HP Sensor Deck Unit -
S115 Lower Path Disengagement HP Sensor - -
S201 Middle Deck Foreign Substance Sensor - -
S202 Middle Deck Open/Close Sensor - -
S203 Middle Deck Pickup Sensor Pickup Unit -
S204 Middle Deck Pull-out Sensor Pickup Unit -
