7. Set the Short Lifter Wire [1] and the Parallel Pin [2] to the Wire Pulley.
8. Install the Wire Pulley [1].
• 1 E ring [2]
9. Turn the Coupling [1] in the arrow direction while pushing it, raise a lifter plate [2] by around 10cm.
10. Install the Deck Unit.
11. Install the Pickup Unit.
12. Install the removed Covers.
4. Parts Replacement and Cleaning
162
