2. Remove the Deck Pull-out Roller [1].
• 1 E ring [2]
• 1 Bearing [3]
[3]
[1]
[2]
3. Remove the One-way Gear [2] and the Bearing [3] from the Deck Pull-out Roller [1].
• 2 E rings [4]
[1]
[2]
[4]
[3]
NOTE:
When installing the One-way Gear [1], install it in the direction shown in the figure.
[1]
4. Parts Replacement and Cleaning
