NOTE:
Service Mode
• Registration of the standard value of A4 paper width on the Multi Deck (Upper):
COPIER> FUNCTION> CST> MDK1-A4
Middle deck and Lower deck uses the following service modes.
(MDK2-A4, MDK3-A4)
• Registration of the standard value of A4 paper width on the Secondary Multi Deck (Upper):
COPIER> FUNCTION> CST> MDK4-A4
Middle deck and Lower deck uses the following service modes.
(MDK4-A4, MDK6-A4)
• Registration of the standard value of A5R paper width on the Multi Deck (Upper):
COPIER> FUNCTION> CST> MDK1-A5R
Middle deck and Lower deck uses the following service modes.
(MDK2-A5R, MDK3-A5R)
• Registration of the standard value of A5R paper width on the Secondary Multi Deck (Upper):
COPIER> FUNCTION> CST> MDK4-A5R
Middle deck and Lower deck uses the following service modes.
(MDK5-A5R, MDK6-A5R)
<Use case>
• When registering the standard value of paper width on the Multi Deck
• Deck Controller PCB exchange/ RAM clear
• Adjustment of Multi Deck (Upper) A4 paper width:
COPIER> ADJUST> CST-ADJ> MDK1-A4
Middle deck and Lower deck uses the following service modes.
(MDK2-A4, MDK3-A4)
• Adjustment of Secondary Multi Deck (Upper) A4 paper width:
COPIER> ADJUST> CST-ADJ> MDK4-A4
Middle deck and Lower deck uses the following service modes.
(MDK5-A4, MDK6-A4)
• Adjustment of Multi Deck (Upper) A5R paper width:
COPIER> ADJUST> CST-ADJ> MDK1-A5R
Middle deck and Lower deck uses the following service modes.
(MDK2-A5R, MDK3-A5R)
• Adjustment of Secondary Multi Deck (Upper) A5R paper width:
COPIER> ADJUST> CST-ADJ> MDK4-A5R
Middle deck and Lower deck uses the following service modes.
(MDK5-A5R, MDK6-A5R)
<Use case>
• Deck Controller PCB exchange/ RAM clear
■ Cassette Heater Control (JP Model only)
To facilitate separation of paper in a high humidity environment, a Cassette Heater Unit is available optionally. When the Cassette
Heater (CHT002/CHT003) is powered, the temperature in the deck becomes suitable and thereby the humidity lowers, facilitating
separation of paper. When the Cassette Heater Switch mounted at the rear of this equipment is set at OFF, the Cassette Heater
(CHT002/CHT003) is not powered. When the Cassette Heater Switch is set to ON, the Cassette Heater is continuously powered.
NOTE:
The Cassette Heater (CHT002/CHT003) can only be mounted in the Middle and Lower Decks because the Upper Deck can be
warmed by these heaters.
