No. Part Name No. Part Name
AHT101 Upper Deck Air Heater Unit S007 Environment Sensor
AHT201 Middle Deck Air Heater Unit S011 Horizontal Path Disengagement HP Sensor 1
AHT301 Lower Deck Air Heater Unit S012 Horizontal Path Disengagement HP Sensor 2
CHT003 Cassette Heater (Lower Deck) (JP Model only) S013 Flapper HP Sensor
CHT002 Cassette Heater (Middle Deck) (JP Model only) S101 Upper Deck Foreign Substance Sensor
FAN001 Power Supply Cooling Fan 1 S102 Upper Deck Open/Close Sensor
FAN002 Power Supply Cooling Fan 2 S103 Upper Deck Pickup Sensor
FAN101 Upper Deck Flotation Fan 1 S104 Upper Deck Pull-out Sensor
FAN102 Upper Deck Flotation Fan 2 S105 Upper Deck Paper Presence/Absence Sensor
FAN201 Middle Deck Flotation Fan 1 S106 Upper Deck Paper Surface Sensor
FAN202 Middle Deck Flotation Fan 2 S109 Upper Deck Lifter Upper Limit Sensor
FAN301 Lower Deck Flotation Fan 1 S110 Upper Deck Relay Paper Sensor
FAN302 Lower Deck Flotation Fan 2 S111 Upper Deck Lifter Lower Limit Sensor
FAN401 Through Path Cooling Fan 1 S112 Upper Deck Paper Length Detection Sensor 1
FAN402 Through Path Cooling Fan 2 S113 Upper Deck Paper Length Detection Sensor 2
FUS001 Leakage Breaker S114 Upper Deck Swing HP Sensor
M001 Vertical Path Upper Feed Motor S115 Lower Path Disengagement HP Sensor
M002 Vertical Path Lower Feed Motor S201 Middle Deck Foreign Substance Sensor
M003 Horizontal Path Feed Motor 1 S202 Middle Deck Open/Close Sensor
M005 Horizontal Path Disengagement Motor 1 S203 Middle Deck Pickup Sensor
M006 Horizontal Path Disengagement Motor 2 S204 Middle Deck Pull-out Sensor
M007 Lower Path Feed Motor S205 Middle Deck Paper Presence/Absence Sensor
M008 Lower Path Disengagement Motor S206 Middle Deck Paper Surface Sensor
M015 Horizontal Path Feed Motor 2 S208 Middle Deck Lifter Upper Limit Sensor
M101 Upper Deck Lifter Motor S210 Middle Deck Relay Paper Sensor
M102 Upper Deck Swing Motor S211 Middle Deck Lifter Lower Limit Sensor
M103 Upper Deck Pickup Motor S213 Middle Deck Paper Length Detection Sensor 1
M104 Upper Deck Pull-out Motor S214 Middle Deck Paper Length Detection Sensor 2
M201 Middle Deck Lifter Motor S215 Middle Deck Swing HP Sensor
M202 Middle Deck Swing Motor S301 Lower Deck Foreign Substance Sensor
M203 Middle Deck Pickup Motor S302 Lower Deck Open/Close Sensor
M204 Middle Deck Pull-out Motor S303 Lower Deck Pickup Sensor
M301 Lower Deck Lifter Motor S304 Lower Deck Pull-out Sensor
M302 Lower Deck Swing Motor S305 Lower Deck Paper Presence/Absence Sensor
M303 Lower Deck Pickup Motor S306 Lower Deck Paper Surface Sensor
M304 Lower Deck Pull-out Motor S308 Lower Deck Lifter Upper Limit Sensor
M401 Through Path Inlet Motor 2 S310 Lower Deck Relay Paper Sensor
M402 Through Path Feed Motor S311 Lower Deck Lifter Lower Limit Sensor
M403 Through Path Outlet Motor 1 S313 Lower Deck Paper Length Detection Sensor 1
M404 Through Path Outlet Motor 2 S314 Lower Deck Paper Length Detection Sensor 2
M405 Through path Disengagement Motor 1 S315 Lower Deck Swing HP Sensor
M406 Through path Disengagement Motor 2 S401 Multi Tray Inlet Sensor
M407 Through Path Inlet Motor 1 S402 Through Path Inlet Sensor
M408 Front Alignment Plate Motor S414 Through Path Front Cover Open/Close Sensor
M409 Rear Alignment Plate Motor S415 Front Alignment Plate HP Sensor
S001 Vertical Path Upper Sensor S420 Through Path Double Feeding Sensor (receive)
S002 Vertical Path Middle Sensor S421 Through Path Double Feeding Sensor (transmis-
sion)
S003 Vertical Path Lower Sensor S501 Upper Double Feeding Sensor (receive)
S004 Horizontal Path Sensor 1 S502 Upper Double Feeding Sensor (transmission)
S005 Horizontal Path Sensor 2 S503 Lower Double Feeding Sensor (receive)
S006 Deck Left Front Cover Open/Close Sensor S504 Lower Double Feeding Sensor (transmission)
2. Technology
43
