9
Access the Page Setup pane.
10
Select and click a roll paper in the A Paper Source list.
11
Make sure the width of the loaded roll is displayed in the BRoll Width list—in this case, ISO A2/A3
(420.0mm).
Note
• If the width of the roll loaded in the printer is not shown in B Roll Width, click L Printer Information on the
Main pane to update the printer information.
12
Make sure
C Page Size on the Page Setup pane
shows the original size as specified in CPaper Size
in the Page Attributes dialog box—in this case, ISO
A3.
13
Specify additional printing conditions.
For details on available printing conditions, see "Printer Driver Settings(Mac OS X) →P.292 "
Printing Line Drawings and Text (Mac OS X)
iPF760
User's Guide
Enhanced Printing Options Printing CAD Drawings
46
