i
Maintenance Cartridge
Absorbs ink used for maintenance purposes such as head cleaning. (Replace the cartridge when it is full.)
j
Cutter Unit
A round-bladed cutter for automatic roll cutting.
k
Cutter Rail
The Cutter Unit passes over this rail to cut paper.
l
Output Tray
All printed documents are ejected from this slot.
m
Ejection Guide
Guides printed documents as they are ejected.
n
Top Cover
Open this cover to install the Printhead and remove any jammed paper from inside the printer, as needed.
(See "Top Cover (Inside).") →P.466
o
Width Guide
When loading the sheets , move the guide to match the paper size.
p
Stand
A stand that holds the printer. Equipped with casters to facilitate moving it. (See "Stand.") →P.469
Side
Side
a
Manual Pocket
Store printer manuals in this pocket.
iPF760
Side
User's Guide
Printer Parts Printer parts
465
