Printheads
Printheads
Printhead ...................................................................................................................................................... 524
Checking for Nozzle Clogging ..................................................................................................................... 524
Cleaning the Printhead ................................................................................................................................. 525
Replacing the Printhead ............................................................................................................................... 526
Printhead
Printhead
A replacement Printhead.
•
Printhead PF-04
Note
• For instructions on replacing the Printhead, see "Replacing the Printhead." →P.526
Checking for Nozzle Clogging
Checking for Nozzle Clogging
If printing is faint or affected by banding in different colors, make sure the Printhead nozzles are clear by printing a
test pattern to check the nozzles.
Note
• Nozzles are periodically checked to ensure they are clear. Configure the settings on the Control Panel menu in Nozzle
Check. (See "Menu Settings.") →P.448
1
Load unused paper.
•
Attaching the Roll Holder to Rolls →P.397
•
Loading Rolls in the Printer →P.399
•
Loading Sheets in the Printer →P.417
2
On the Tab Selection screen of the Control Panel, press
◀ or ▶ to
select the Settings/Adj. tab ( ).
Note
• If the Tab Selection screen is not displayed, press the Menu button.
3
Press the OK button.
The Set./Adj. Menu is displayed.
4
Press ▲ or ▼ to select Test Print, and then press the OK button.
5
Press ▲ or ▼ to select Nozzle Check, and then press the OK button.
The printer now prints a test pattern for checking the nozzles.
Printhead
iPF760
User's Guide
Maintenance and Consumables Printheads
524
