CAPINTEC, INC. CRC
®
-25R
8. If any line in the group just printed does not match the corresponding line in
Figure 5-13 Listing of the Turbo OKIDATA 320 Printer Setup Data, it must be
corrected. For example, to change the Baud Rate to 4800:
A. Press the GROUP button until Serial I/F is printed.
B. Press the ITEM button until Baud Rate is printed.
C. Press the SET button until 4800 BPS is printed.
9. If any differences remain, return to step 6 for the next group.
10. Press the SHIFT + MENU (SEL) buttons to return to SEL (on-line).
Note: The Setup printout shown in Figure 5-13 Listing of the Turbo OKIDATA 320
Printer Setup Data is for example only. Your printer Setup may differ slightly
from that shown. Verify that the settings, which are the same between your
Setup and that shown, concur.
5 - 8 SYSTEM INITIALIZATION March 15
