E-004 W-O/4 Upstream Oxygen Sensor D3
E-005 W-O/4 Downstream Oxygen Sensor D4
E-006 B/3 Crankshaft Position Sensor D3
E-007 W/2 Camshaft Position Sensor D3
E-008 W/2 Generator D2
E-014 B/1 Power Steering Switch C2
E-015 B/1 A/C Compressor C2
E-016 W/1 Oil Pressure Switch C2
E-017 B/3 Knock Sensor C3
E-018 B/1 Starter Motor C3
E-019 B/2 Engine Coolant Temperature Sensor D4
E-020 B/4 Ignition Coil D4
E-021 B/2 Backup Lamp Switch C4
E-022 B/2 Canister Control Valve D4
E-027 B/6 Electronic Throttle Control Actuator D3
E-030 B/1 Battery D5
E-031 B/1 Starter Motor C3
E-032 B/1 Generator D2
E-033 B/4 Manifold Absolute Pressure Sensor E3
E-100 B/42 To E-700 D4
E-101 B/6 To E-400 C3
E-301 B/2 Fuel Injector No.1 D2
E-302 B/2 Fuel Injector No.2 D2
E-303 B/2 Fuel Injector No.3 D3
E-304 B/2 Fuel Injector No.4 D3
E-400 B/2 To E-101 C3
E-601 B/81 ECM (Engine Control Module) E4
E-700 B/42 To E-100 D4
E-701 B/16 A-101 D4
E-702 B/22 To C-100 E4
E-801 - Ground E4
E-802 - Ground E4
VEHICLE HARNESS ROUTING MAPS
16
16–37
Chery Automobile Co., Ltd.
