Operation
The differential operates through the gear mesh with the ring gear bolted to the differential case. The engine power
is transmitted to the axle shafts through the pinion mate and side gears. The side gears are connected to the axle
shafts.
Specifications
Clearance Specifications
DESCRIPTION CLEARANCE (mm)
Clearance between side gear and planetary gear 0.025 - 0.150
Adjusting washer 0.93 - 1.00
Special Tools
Bearing Remover
MD-998801
Differential Seal Installer
CH-30002
GENERAL INFORMATION
08–38
Chery Automobile Co., Ltd.
