Engine Will Not Crank
The following conditions apply to this symptom:
• The engine will not crank.
1.
PRELIMINARY CHECKS
• Carry out the following preliminary vehicle inspection:
− Fuel quality
− Battery connections
− Starter relay connections
− Manual transmission clutch fully depressed
− Engine Immobilizer activated
− Fuses/Fuse links
Is the check result normal?
Yes
>> Go to the next step.
No
>>
Repair as necessary.
Verify the symptom no longer exists.
2.
LISTEN FOR STARTER RELAY CLICKING
• Attempt to start the engine.
Is a clicking sound heard from the starter relay when the ignition key is turned to START?
Yes
>> Go to the next step.
No
>> Go to step 5.
3.
CHECK STARTING SYSTEM
• Check the starter, starter ground, starter relay cable to starter and battery.
Is a fault indicated?
Yes
>> Repair as necessary.
No
>> Go to the next step.
4.
CHECK OPERATION OF OTHER ELECTRICAL ACCESSORIES
• Check all accessories.
Do any other electrical accessories work?
Yes
>> Go to the next step.
No
>> Check the charging system.
5.
CHECK DTC
• Turn the ignition switch on.
• With the X-431 scan tool, read the DTC.
Are there any DTCs present?
Yes
>> Check for cause.
No
>> Go to the next step.
ELECTRONIC ENGINE CONTROLS - ENGINE SYMPTOM DIAGNOSIS
03–182
Chery Automobile Co., Ltd.
