INTERIOR LAMPS
Description
The interior lamps are controlled by the Body Control Module (BCM). The interior lamps consist of the following:
• Front Dome Lamp
• Backlight Adjusting Switch
• Instrument Cluster
• Headlamp Aiming Switch
• Combination Lamp Switch
• Hazard Switch
• Console Power Socket (Illumination)
• Audio Unit
• Door Mirror Remote Control Switch
• Main Power Window Switch
• Front Power Window Switch
• Rear Power Window Switch
• Rear Hatch Lamp
Operation
The Body Control Module (BCM) receives switch inputs and controls voltage output to the interior lamps. The supply
voltage is transmitted from the fuse box to the lamps.
