POWER WINDOWS
Description
The power window system allows each of the door windows to be raised and lowered electronically by activating a
switch on each door trim panel. The driver8s window switch allows the driver to lock out the individual rear window
switches from operation. The power window system includes the power window switches on the driver’s door trim
panel, passenger door and rear doors, and the power window motors.
Operation
The front and rear power window motors are a permanent magnet type. A battery positive and negative connection
to either of the two motor terminals will cause the motor to rotate in one direction. Reversing current through these
same two connections will cause the motor to rotate in the opposite direction. Each individual motor is grounded
through their respective switch.
15
15–99
Chery Automobile Co., Ltd.
