Fuel Injector Inspection
1. Remove the fuel injector electrical connector.
2. Use a digital multimeter to measure the resistance between the two fuel injector pins (fuel injector side).
SPECIFICATION TEMPERATURE
11 - 16 V 20°C
Fuel Tank
Description
The fuel tank is constructed of a plastic composite material. The fuel tank stores fuel and the fuel pump module is
mounted in the fuel tank.
Operation
The fuel tank is used for fuel storage. The fuel pump is mounted in the fuel tank and delivers fuel from the tank to
the entire fuel system.
Removal & Installation
WARNING!
Release the fuel system pressure before servicing any fuel system components. Service vehicles in well venti-
lated areas and avoid ignition sources. Never smoke while servicing the vehicle. This may result in personal
injury or death.
1. Release the fuel system pressure (See Fuel Pressure Relief Procedure in Section 04 Fuel Delivery).
2. Remove the negative battery cable.
3. Remove the rear seat cushion (See Rear Seat Removal & Installation in Section 15 Body & Accessories).
4. Remove the fuel pump (See Fuel Pump Removal & Installation in Section 04 Fuel Delivery).
5. Drain the fuel from the tank.
ON-VEHICLE SERVICE
04–18
Chery Automobile Co., Ltd.
