Spark Plug Wire
Removal & Installation
1. Disconnect the negative battery cable.
2. Twist the spark plug wire from the ignition coil and remove the spark plug wire.
3. Twist the spark plug wire (1) from the spark plug,
then pull the spark plug wire straight up away from
the engine.
4. Remove the spark plug wires (1).
Cylinder Number 1 2 3 4
Length (mm) 690 525 450 380
Resistance (kV/m) 16 ± 20% 16 ± 20% 16 ± 20% 16 ± 20%
Diameter (mm) 7 7 7 7
5. Installation is in the reverse order of removal.
ON-VEHICLE SERVICE
PZSM030016
PZSM030007
03
03–205
