Front Door LH Harness
D-001 Y/16 Main Power Window and Door Lock/Unlock Switch
D-002 W/2 Front Power Window Motor LH
D-003 B/3 Outside Mirror LH
D-004 B/2 Front Speaker LH
D-005 B/10 Outside Mirror Remote Control Switch
D-006 B/4 Front Door Lock Assembly LH
D-007 W/2 Security Lamp
D-101 W/14 To B-101
D-102 W/10 To B-102
VEHICLE HARNESS ROUTING MAPS
PZSMW160006T
16–44
Chery Automobile Co., Ltd.
