B-001 W/16 BCM (Body Control Module) C3
B-002 B/25 BCM (Body Control Module) C3
B-004 W/6 Rear Combination Lamp LH D5
B-005 W/6 Rear Combination Lamp RH E3
B-007 W/2 Seat Belt Buckle Switch C4
B-008 B/2 Front Dome Lamp Assembly E2
B-015 B/1 Parking Brake Switch C3
B-017 B/2 Rear Speaker LH D4
B-018 B/2 Rear Speaker RH E3
B-021 B/2 Rear Wheel Speed Sensor LH C4
B-022 B/2 Wheel Speed Sensor RH D4
B-032 B/4 Fuel Lever Sensor and Fuel Pump D4
B-034 W/2 Trunk Lamp D5
B-042 w/1 Front Door Unlock Switch LH C4
B-043 w/1 Rear Door Unlock Switch LH C4
B-044 B/4 Front Door Unlock Switch RH D2
B-045 W/18 Rear Door Unlock Switch RH D3
B-050 W/14 Sunroof Control Module E3
B-101 W/14 To D-101 C1
B-102 W/10 To D-102 C1
B-103 B/10 To I-100 C4
B-104 W/15 To A-104 C2
B-105 W/26 To C-105 C3
B-106 W/4 To C-106 C2
B-107 W/10 To G-100 D1
B-108 W/6 To G-101 D1
B-109 W/10 To H-104 D2
B-110 W/6 To L-100 E5
B-111 W/2 To B-401 D4
B-120 W/2 Sonar Module D5
B-201 - Ground E3
B-202 - Ground D5
B-203 - Ground C3
B-204 - Ground D3
B-205 - Ground C3
VEHICLE HARNESS ROUTING MAPS
16
16–43
Chery Automobile Co., Ltd.
