GENERAL INFORMATION
Description
The power steering pump is a constant flow rate and displacement vane type pump. The pump reservoir is detached
from the pump body. The pump is connected to the steering gear by the pressure and return lines.
Operation
The power steering pump is mounted to the engine and driven by the engine accessory drive belt. Power steering
fluid enters the pump from the reservoir. The power steering fluid is then trapped between the pump vanes and
moved to the high-pressure side of the pump creating a flow of fluid. The restriction of this flow by the steering gear
creates the pressure that provides the steering assist.
Specifications
Torque Specifications
DESCRIPTION TORQUE (N·m)
Power Steering Pressure Line To Steering Gear 25 ± 5
Power Steering Return Line To Steering Gear 25 ± 5
Power Steering Pressure Line To Power Steering Pump 45 ± 5
Power Steering Pump Mounting Bolts 25 ± 5
Pressure/Return Hose Routing Clamp Screws To Cross
Member
10
Fluid Specifications
DESCRIPTION CAPACITY (L)
Power Steering Fluid (ATF III) 1.0
11–38
