DESCRIPTION ITEM STANDARD LIMIT
Camshaft Cam Bearing #1
Inner Diameter
- 32 - 32.025 mm -
Camshaft Cam Bearing
#2, #3, #4, #5, Inner
Diameter
- 24 - 24.021 mm -
Camshaft Journal #1
Clearance
- 0.05 - 0.090 mm -
Camshaft Journal #2, #3,
#4, #5 Clearance
- 0.04 - 0.074 mm -
Intake Camshaft Axial
Clearance
- 0.15 - 0.20 mm -
Exhaust Camshaft Axial
Clearance
- 0.15 - 0.20 mm -
Intake Valve Guide
Clearance
- 0.012 - 0.043 mm -
Exhaust Valve Guide
Clearance
- 0.032 - 0.063 mm -
Valve Outer Diameter
Intake Valve 5.98 ± 0.008 mm -
Exhaust Valve 5.96 ± 0.008 mm -
Valve Guide Inner
Diameter
Intake Valve 5.4 ± 0.1 mm -
Exhaust Valve 5.4 ± 0.1 mm -
Fringe Thickness On Top
Of Valve
Intake Valve 0.3 ± 0.15 mm -
Exhaust Valve 0.3 ± 0.15 mm -
Valve Tilt Angle
Intake Valve 65° -
Exhaust Valve 68° -
Valve Height
Intake Valve 107.998 mm -
Exhaust Valve 106.318 mm -
Torque Specifications
CAUTION:
When torquing a fastener in two steps, DO NOT use a torque wrench for the second step.
DESCRIPTION TORQUE (N·m)
A/C Compressor Line Bolt 20 ± 5
Camshaft Bearing Cap Bolts 9.5 ± 1.5
Clutch Pressure Plate Bolts 25 ± 5
Connecting Rod Cap Bolts
1st Step: Tighten the bolt to 25 ± 3 N·m
2nd Step: Tighten the bolt an additional 90 ± 5°
Crankshaft Holder 28
Crankshaft Main Bearing Cap Bolts
1st Step: Tighten the bolt to 45 ± 5 N·m
2nd Step: Tighten the bolt an additional 180 ± 10°
Crankshaft Timing Belt Pulley Bolt
1st Step: Tighten the bolt to 130 ± 10 N·m
2nd Step: Tighten the bolt an additional 65 ± 5°
Crankshaft Vibration Damper Bolts
25 ± 5
2nd Step: Tighten the bolt an additional 30 ± 5°
Camshaft Timing Belt Pulley Bolt 120 ± 5
Cylinder Head Cover Bolts 10 ± 2
GENERAL INFORMATION
02
02–5
Chery Automobile Co., Ltd.
