DESCRIPTION TORQUE (N·m)
Cylinder Head Bolts
1st Step: Tighten the bolt to 50 ± 5 N·m
2nd Step: Tighten the bolt an additional 90 ± 5°
3rd Step: Tighten the bolt an additional 90 ± 5°
Dipstick Bracket Bolts 10 ± 2
Engine Left Mount Bolt 65 ± 5
Engine Right Mount Bolt 65 ± 5
Engine Front Mount Bolt 80 ± 5
Engine Rear Mount Bolt 60 ± 5
Engine To Transaxle Bolts 70 ± 5
Exhaust Manifold Nuts 20 ± 5
Exhaust Manifold To Catalytic Converter Bolts 60 ± 5
Exhaust Manifold Heat Shield Bolts 10 ± 5
Exhaust Camshaft Timing Belt Pulley Bolt 120 ± 5
Fuel Rail Bracket Bolts 10 ± 3
Flywheel Bolt
1st Step: Tighten the bolt to 15 ± 5 N·m
2nd Step: Tighten the bolt an additional 30 ± 5°
Idler Pulley Bolt 40 ± 5
Intake Camshaft Timing Belt Pulley Bolt 120 ± 5
Intake Manifold Bolts 8 ± 3
Intake Manifold Nuts 8 ± 3
Intake Manifold Bracket Bolts 20 ± 5
Lower Idler Pulley Bolt 40 ± 5
Lower Cylinder Block Bolts 25 ± 5
Oil Filter 25 ± 3
Oil Pan Bolts 15 ± 5
Oil Drain Plug 25 ± 3
Oil Strainer Bolts 18
Oil Pump Bolts
8 ± 3
(Apply with Loctite 5910 Thread-Locker)
Rear Timing Cover Bolts 8 ± 3
Timing Belt Upper Cover Bolts 8 ± 3
Timing Belt Lower Cover Bolts 8 ± 3
Timing Belt Tensioner Assembly 27 ± 3
Timing Belt Tensioner Pulley Bolt 45 ± 5
Shift Cable Bracket Bolts 25 ± 5
Throttle Body Bolts 8 ± 3
Upper Idler Pulley Bolt 45 ± 5
GENERAL INFORMATION
02–6
Chery Automobile Co., Ltd.
