2. Remove the clamps (1) between the intake mani-
fold and the air cleaner housing.
3. Remove the PCV return hose clamp (1) on the
intake manifold hose.
4. Remove the intake manifold hose.
5. Remove the two air cleaner housing retaining bolts
(1).
(Tighten: Air cleaner housing bolts to 10 ± 5 N·m)
6. Remove the air cleaner housing.
7. Installation is in the reverse order of removal.
Cylinder Head Cover
Removal & Installation
1. Disconnect the negative battery cable.
ON-VEHICLE SERVICE
PZSM020003
PZSM020046
PZSM020002
02
02–19
Chery Automobile Co., Ltd.
