2. Remove the clamps (1) between the intake mani-
fold and the air cleaner housing.
3. Remove the PCV return hose clamp (1) on the
intake manifold hose.
4. Remove the intake manifold hose.
5. Disconnect the manifold air pressure (MAP) sensor
electrical connector.
6. Remove the MAP sensor retaining bolt (1) and
remove the MAP sensor.
7. Remove the four spark plug wires (1) and set them
aside.
ON-VEHICLE SERVICE
PZSM020003
PZSM020046
PZSM030004
PZSM030016
02–20
Chery Automobile Co., Ltd.
