8. Remove the PCV hose clamp (1) and remove the
PCV hose from the cylinder head cover.
9. Remove the fuel vapor return hose clamp (1) and
remove the fuel vapor return hose from the throttle
body.
10. Disconnect the Camshaft Position (CMP) sensor
electrical connector.
11. Remove the CMP sensor retaining bolt (1) and
remove the CMP sensor.
ON-VEHICLE SERVICE
PZSM030019
PZSM030018
PZSM030011
02
02–21
Chery Automobile Co., Ltd.
To Next Page
