GENERAL INFORMATION
Description
The parking brakes consist of the following components:
• Hand-operated parking brake lever
• Parking brake cables (one each side)
• Parking brake controls
Operation
All vehicles are equipped with a center-mounted, hand-operated parking brake lever mounted between the front
seats. A tensioner is built into the equalizer mounted on the end of the lever’s output cable. There is an individual
parking brake cable for each rear wheel that joins a parking brake cable equalizer, attached to the parking brake
lever, to the rear parking brakes. The parking brake cables are made of flexible steel cable.
Specifications
Torque Specifications
DESCRIPTION TORQUE (N·m)
Parking Brake Cable Bracket Bolts 9 - 12
Wheel Mounting Nuts 110
Special Tools
Brake Measuring Gauge
12
12–81
Chery Automobile Co., Ltd.
