P0604 - Micro Processor Error
P060C - Main Micro Processor Error (MMP)
P0613 - Safety Micro Processor Error (SMP)
On Board Diagnostic Logic
• Self-diagnosis detection logic.
DTC NO. DTC DEFINITION
DTC DETECTION
CONDITION
DTC SET
CONDITION
POSSIBLE CAUSE
P0604
Micro processor
error
Ignition switch: ON
• Automated Manual
Transaxle (AMT)
control module
detected an internal
failure.
• If the DTC was
set, then the AMT
can be only shifted
up to 3rd gear
forcibly.
• Harness is open or
shorted
• AMT control
module
P060C
Main micro
processor error
(MMP)
P0613
Safety micro
processor error
(SMP)
DTC Confirmation Procedure:
Before performing the following procedure, confirm that battery voltage is more than 12 V.
• Turn ignition switch off.
• Connect the X-431 scan tool to the Data Link Connector (DLC) - use the most current software available.
• Turn ignition switch on.
• With the scan tool, record and erase stored DTCs in the Automated Manual Transaxle (AMT) control module.
• Turn ignition switch off, and then turn the ignition switch on.
• With the scan tool, select view DTC and data stream in the AMT control module.
• If the DTC is detected, the DTC condition is current. Go to Diagnostic Procedure - Step 1.
• If the DTC is not detected, the DTC condition is intermittent (See Diagnostic Help and Intermittent DTC Trou-
bleshooting in Section 08 Transaxle for more information).
NOTE :
• Troubleshoot any Engine Control Module (ECM) charging/cranking DTCs before proceeding.
• The following tools are required to perform the following test:
• X-431 Scan Tool
• Digital Multimeter
DIAGNOSIS & TESTING
08
08–71
