5.
CHECK THE BATTERY
Maintain engine speed above 1000 RPM for a few minutes.
Turn ignition switch off.
Measure the voltage drop at the battery positive and negative terminals while cranking the engine.
Battery voltage should be more than approximately 9.0 V.
Is the check result normal?
Yes
>> Go to step 6.
No
>> Charge or replace the battery.
6.
CHECK AMT CONTROL MODULE SUPPLY CIRCUIT
Turn the ignition switch off.
Disconnect the battery positive terminal.
Measure continuity between the AMT control module connector terminal 25 and the battery positive terminal.
Continuity should exist.
Is the check result normal?
Yes
>> Go to the next step.
No
>>
Check fuse.
Check the electrical harness for an open or high resistance.
7.
CHECK DTC
With the X-431 scan tool, read AMT control module DTCs.
Refer to 9DTC Confirmation Procedure9.
Is DTC P0560 still present?
Yes
>> Replace the AMT control module (See AMT control module Removal & Installation in Section 08
Transaxle).
No
>>
The system is now operating properly.
Reassemble the vehicle and road test to verify the customers complaint is repaired.
DIAGNOSIS & TESTING
08–70
Chery Automobile Co., Ltd.
