4.
CHECK TPS POWER SUPPLY CIRCUIT
Turn ignition switch off.
Disconnect the ECM electrical connector.
Check the continuity between TPS terminal 3 and ECM terminal 32.
Check the continuity between TPS terminal 3 and ECM terminal 73.
Continuity should exist.
Is the check result normal?
Yes
>> Go to the next step.
No
>>
Repair or replace circuit for an open.
If the circuit is normal, go to the next step.
5.
CHECK TPS POWER SUPPLY CIRCUIT
Check harness for short to power and short to ground, between the following terminals:
TPS POWER SUPPLY
ECM TERMINAL TPS / APPS TERMINAL
32 or 73 TPS terminal 3
32 or 73 APP sensor terminal 3
33 APP sensor terminal 6
Is the check result normal?
Yes
>> Go to the next step.
No
>> Repair circuit for a short to ground or short to power in harness or connectors.
DIAGNOSIS & TESTING
03
03–115
Chery Automobile Co., Ltd.
