2.
CHECK THE ELECTRONIC THROTTLE CONTROL ACTUATOR
• Check the electronic throttle opening degrees.
• Check the electronic throttle clearance.
Is the check result normal?
Yes
>> Go to the next step.
No
>> Clean or replace as necessary.
3.
CHECK DTC
• With the X-431 scan tool, read ECM DTCs.
• Refer to 9DTC Confirmation Procedure9.
Is DTC P0506 still present?
Yes
>> Replace the ECM.
NOTE : The Immobilizer control module must be matched to the new ECM (See ECM Removal & Instal-
lation in Section 03 Electronic Engine Controls).
No
>>
The system is now operating properly.
Reassemble the vehicle and road test to verify the customers complaint is repaired.
