GENERAL INFORMATION
Description
The 1.3L in-line four cylinder engine has the following features:
• Double overhead camshafts
• Four valves per cylinder
• Aluminum cylinder head
• Cast iron cylinder block
Operation
The 1.3L engine utilizes 4 valve-per-cylinder and a double overhead camshaft design. The engine uses an individual
coil ignition system. The cylinder block is made of cast iron and the bearing caps are integrated into the lower cyl-
inder block assembly. An aluminum oil pan bolts to the bottom of the lower cylinder block. The camshafts are
mounted in the cylinder head and act against valve tappets to open and close the valves. The camshafts are driven
off the front of the cylinder head by one timing belt. The belt is driven by a sprocket that is located on the crankshaft.
The piston assembly is an aluminum piston with a cast iron connecting rod.
The aluminum cylinder head contains double overhead camshafts with four valves per cylinder. The valves are
arranged in two in-line banks. The cylinder head incorporates powdered metal valve guides and seats. The cylinder
head is sealed to the block using a multi-layer steel head gasket and retaining bolts.
Specifications
1.3L Engine Specifications
DESCRIPTION SPECIFICATION
Type In-Line OHV, DOHC
Number of Cylinders 4
Compression Ratio 10.0:1
Compression Pressure 10.0 - 13.5 bar
Max. Compression Pressure Variation Between
Cylinders
30%
Stroke 77.5 mm
Cylinder Volume 1.297 L
Bore 73 mm
Fuel Designation (Not less than) #93
Engine Oil Quantity 3.5 L
Fuel Supply Mode Multi-Point Electronic Controlled Gasoline Injection
Engine Oil Designation SAE 10W-40 (Grade SL or above)
Displacement 1297 cc
Firing Order 1-3-4-2
02
02–3
Chery Automobile Co., Ltd.
