GENERAL INFORMATION
Description
The fuel system consists of a fuel tank with a reservoir, fuel pump, fuel filter, fuel line, fuel rail, fuel injectors. The
Engine Control Module (ECM) controls the fuel system based on signal inputs. The Immobilizer control module sig-
nals the ECM to activate the fuel system. If the ECM does not receive the proper signal from the Immobilizer control
module, the ECM will not allow the fuel system to operate.
• The ACTECO engine utilizes a returnless fuel delivery system.
1 - EVAP Canister
2 - Fuel Filter
3 - Fuel Pump
4 - Fuel Tank
5 - Fuel Lines
6 - Fuel Rail and Fuel Injectors
7 - EVAP Canister Purge Solenoid
PZSM040010
04–2
