Positive Battery Cable
Removal & Installation
1. Disconnect the negative battery terminal.
2. Disconnect the positive battery terminal.
3. Remove the battery cable from the B+ terminal of the generator.
4. Remove the battery cable from the B+ terminal of the starter motor.
5. One at a time, trace the battery cable retaining push pins, fasteners and routing clips until the cables are free
from the vehicle.
6. Remove the battery cable from the engine compartment.
7. Installation is in the reverse order of removal.
Negative Battery Cable
Removal & Installation
1. Disconnect the negative battery terminal.
2. Remove the bolts securing the negative cable to the body ground.
3. One at a time, trace the battery cable retaining push pins, fasteners and routing clips until the cables are free
from the vehicle.
4. Remove the battery cable from the engine compartment.
5. Installation is in the reverse order of removal.
Starter Motor Assembly
Description
The starter motor is mounted with two bolts to the transaxle housing and is located on the side of the engine. The
starter motor incorporates several features to create a reliable, efficient, compact, lightweight and powerful unit. The
electric motor of the starter features electromagnetic field coils wound around pole shoes, and brushes contact the
motor commutator. The starter motor is serviced only as a unit and cannot be repaired.
Operation
The starter motor is equipped with a planetary gear reduction system. The planetary gear reduction system consists
of a gear that is integral to the output end of the electric motor armature shaft that is in continual engagement with
a larger gear that is splined to the input end of the starter pinion gear shaft. This feature makes it possible to reduce
the dimensions of the starter. At the same time, it allows higher armature rotational speed and delivers increased
torque through the starter pinion gear to the starter ring gear.
ON-VEHICLE SERVICE
05
05–9
Chery Automobile Co., Ltd.
