On Board Diagnostic Logic
• Self-diagnosis detection logic.
DTC NO. DTC DEFINITION
DTC DETECTION
CONDITION
DTC SET
CONDITION
POSSIBLE CAUSE
P0715 Clutch speed Vehicle is driving
• The Automated
Manual Transaxle
(AMT) control
module will set this
DTC if the AMT
control module does
not receive a pulse
signal from the
clutch speed sensor,
or the pulse signal is
incorrect when the
vehicle is driving.
• If this DTC is set,
the AMT can only be
shifted up to 3rd
gear forcibly.
• Clutch speed
sensor
• Clutch position
sensor
• Clutch skid
• Harness or
connectors (The
sensor circuit is open
or shorted)
• Automated Manual
Transaxle internal
fault
• AMT control
module
DTC Confirmation Procedure:
Before performing the following procedure, confirm that battery voltage is more than 12 V.
• Turn ignition switch off.
• Connect the X-431 scan tool to the Data Link Connector (DLC) - use the most current software available.
• Turn ignition switch on, with the scan tool, view and erase stored DTCs in the Automated Manual Transaxle
(AMT) control module.
• Start the engine and warm it to normal operating temperature.
• Drive the vehicle up to 10 km/h or more.
• With the scan tool, select view DTC and data stream.
• If the DTC is detected, the DTC condition is current. Go to Diagnostic Procedure - Step 1.
• If the DTC is not detected, the DTC condition is intermittent (See Diagnostic Help and Intermittent DTC Trou-
bleshooting in Section 08 Transaxle for more information).
NOTE :
• If DTC P0720 or P0805 are also present, diagnose and repair them before continuing with this test.
• Using the appropriate diagnostic test tool, you can diagnose the AMT control module harness while the AMT con-
trol module is still connected. This will help prevent electrical connector terminal damage.
DIAGNOSIS & TESTING
08–74
Chery Automobile Co., Ltd.
