7. Release the clutch cable (1) from the release shaft
arm.
8. Remove the AMT valve and hydraulic actuator assembly.
Installation Notes:
• During assembly, ensure that the clutch cable is
installed in a loose state, with the distance between
clutch cable control actuator to clutch control arm
at 38 mm - 42 mm.
ON-VEHICLE SERVICE
PZSM080061
PZSM080063
08–104
