Chery A1 2009 User Manual

ON-VEHICLE SERVICE
Rear Hub and Bearing
Removal & Installation
1. Raise and support the vehicle.
2. Remove the wheel mounting nuts and the tire and wheel assembly.
(Tighten: Wheel mounting nuts to 110 N·m)
3. Remove the rear axle hub nut cover.
4. Remove the rear axle hub nut (1).
(Tighten: Rear axle hub nut to 135 N·m)
5. Remove the rear brake drum (2).
6. Remove the rear hub and bearing (1).
7. Installation is in the reverse order of removal.
PZSM090002
PZSM090003
09–12
Chery Automobile Co., Ltd.
