Front Axle Alignment Specifications
FRONT WHEEL ALIGNMENT PREFERRED SETTING ACCEPTABLE RANGE
Camber +52’ +1°40’ to +2’
Caster +3°24’ +3°54’ to +2°54’
Toe-Individual +6’ 0’ to +12’
Rear Axle Alignment Specifications
REAR WHEEL ALIGNMENT PREFERRED SETTING ACCEPTABLE RANGE
Camber 0’ -30’ to +30’
Toe-Individual 0’ -10’ to +10’
GENERAL INFORMATION
10
10–41
Chery Automobile Co., Ltd.
