9. Remove the steering column retaining bolts (1).
10. Remove the steering assembly carefully.
11. Remove the eight HVAC housing assembly retain-
ing nuts (1).
12. Remove the inlet and outlet A/C pressure line snap rings from the evaporator, and remove the A/C pressure
lines.
13. Remove the HVAC housing assembly.
ON-VEHICLE SERVICE
PZSM130029
PZSM130024
13
13–25
Chery Automobile Co., Ltd.
