SEATS
General Information
Description
The power seat switches are on the outboard side of the seat near the floor. The power seat system is capable of
allowing a user to adjust the power seat to the desired driving position.
Operation
Use the switch to move the seat up, down, forward, rearward, or to tilt the seat. The power seat can be adjusted to
control eight different seating positions.
Front Seat
Removal & Installation
NOTE :
The removal & installation of the left seat is shown, the right seat is similar.
1. Move the seat to the furthest rearward position.
2. Remove the front seat mounting bolts (1) from the
front of the seat guide rail.
3. Move the seat to the furthest frontward position
and remove the protective cover from the guide
rail.
4. Remove the front seat mounting bolts (2) from the
back of the seat guide rail.
PZSM150103
15–114
Chery Automobile Co., Ltd.
