BODY DIMENSIONS
Description
• All measurements should be made from the bare metal, remove trim and bumper covers as necessary.
• Repair any badly damaged areas before taking measurements for underbody alignment.
• Monitor the upper body structure for excessive stress or movement while making any corrections to the under-
body structure.
• Remove all the necessary glass to prevent breakage.
• All dimensions are shown in millimeters (mm).
Front View
Body Front View Dimensions (Units: mm)
PZSM150001
15–154
Chery Automobile Co., Ltd.
To Next Page
