Cisco ASR 9000 Series Reference Guide

ModificationRelease
The following keywords were added:
•
ipv4
•
ipv6
•
l2tp static
•
source
Release 4.3.1
Usage Guidelines
To use this command, you must be in a user group associated with a task group that includes appropriate task
IDs. If the user group assignment is preventing you from using a command, contact your AAA administrator
for assistance.
A cross-connect may have two segments:
1
An Attachment Circuit (AC)
2
An second AC or a pseudowire
The pseudowire is identified by two keys: neighbor and pseudowire ID. There may be multiple pseudowires
going to the same neighbor. It is not possible to configure only a neighbor.
Note
All L2VPN configurations can be deleted using the no l2vpn command.
Task ID
OperationsTask ID
read, writel2vpn
Examples
This example shows a point-to-point cross-connect configuration (including pseudowire configuration):
RP/0/RSP0/CPU0:router# configure
RP/0/RSP0/CPU0:router(config)# l2vpn xconnect group l2vpn
RP/0/RSP0/CPU0:router(config-l2vpn-xc)# p2p rtrA_to_rtrB
RP/0/RSP0/CPU0:router(config-xc-p2p)# neighbor 10.1.1.2 pw-id 1000 pw-class class12
RP/0/RSP0/CPU0:router(config-xc-p2p)# neighbor 10.1.1.3 pw-id 1001 pw-class class13
RP/0/RSP0/CPU0:router(config-xc)# p2p rtrC_to_rtrD
RP/0/RSP0/CPU0:router(config-xc-p2p)# neighbor 10.2.2.3 pw-id 200 pw-class class23
RP/0/RSP0/CPU0:router(config-xc-p2p)# neighbor 10.2.2.4 pw-id 201 pw-class class24
This example shows a point-to-point cross-connect configuration (including pseudowire configuration):
RP/0/RSP0/CPU0:router# configure
RP/0/RSP0/CPU0:router(config)# l2vpn xconnect group l2vpn
RP/0/RSP0/CPU0:router(config-l2vpn-xc)# p2p rtrA_to_rtrB
RP/0/RSP0/CPU0:router(config-xc-p2p)# neighbor 10.1.1.2 pw-id 1000 pw-class foo
RP/0/RSP0/CPU0:router(config-xc)# p2p rtrC_to_rtrD
RP/0/RSP0/CPU0:router(config-xc-p2p)# neighbor 20.2.2.3 pw-id 200 pw-class bar1
Cisco ASR 9000 Series Aggregation Services Router VPN and Ethernet Services Command Reference, Release
6.1.x
115
Point to Point Layer 2 Services Commands
neighbor (L2VPN)
