Cisco Catalyst 3750-X Command Reference

2-981
Catalyst 3750-X and 3560-X Switch Command Reference
OL-29704-01
Chapter 2 Catalyst 3750-X and 3560-X Switch Cisco IOS Commands
vlan
Examples This example shows how to add an Ethernet VLAN with default media characteristics. The default
includes a vlan-name of VLANxxx, where xxxx represents four numeric digits (including leading zeros)
equal to the VLAN ID number. The default media option is ethernet; the state option is active. The
default said-value variable is 100000 plus the VLAN ID; the mtu-size variable is 1500; the stp-type
option is ieee. When you enter the exit config-vlan configuration command, the VLAN is added if it did
not already exist; otherwise, this command does nothing.
This example shows how to create a new VLAN with all default characteristics and enter config-vlan
mode:
Switch(config)# vlan 200
Switch(config-vlan)# exit
Switch(config)#
This example shows how to create a new extended-range VLAN with all the default characteristics, to
enter config-vlan mode, and to save the new VLAN in the switch startup configuration file:
Switch(config)# vtp mode transparent
Switch(config)# vlan 2000
Switch(config-vlan)# end
Switch# copy running-config startup config
You can verify your setting by entering the show vlan privileged EXEC command.
Related Commands
VTP v2 mode is enabled, and you
are configuring a TrBRF VLAN
media type.
Specify a bridge number. Do not leave this field blank.
VTP v1 mode is enabled. No VLAN can have an STP type set to auto.
This rule applies to Ethernet, FDDI, FDDI-NET, Token Ring, and
Token Ring-NET VLANs.
Add a VLAN that requires
translational bridging (values are
not set to zero).
The translational bridging VLAN IDs that are used must already
exist in the database.
The translational bridging VLAN IDs that a configuration points
to must also contain a pointer to the original VLAN in one of the
translational bridging parameters (for example, Ethernet points to
FDDI, and FDDI points to Ethernet).
The translational bridging VLAN IDs that a configuration points
to must be different media types than the original VLAN (for
example, Ethernet can point to Token Ring).
If both translational bridging VLAN IDs are configured, these
VLANs must be different media types (for example, Ethernet can
point to FDDI and Token Ring).
Table 2-59 VLAN Configuration Rules (continued)
Configuration Rule
Command Description
show vlan Displays the parameters for all configured VLANs or one VLAN (if the
VLAN ID or name is specified) in the administrative domain.

Cisco Catalyst 3750-X Specifications

General

Switching Capacity	160 Gbps
Stacking Bandwidth	64 Gbps
Max Stacking Units	9
Layer Support	Layer 2 and Layer 3
Form Factor	Rack-mountable
DRAM	256 MB
Flash Memory	64 MB
Model	Cisco Catalyst 3750-X Series
Ports	24 or 48 10/100/1000 Ethernet ports
Uplink Interfaces	4 SFP or 2 SFP+
Features	StackWise Plus, EnergyWise
Image	IP Base or IP Services
Operating Temperature	0 to 40°C
Operating Humidity	10 to 85% noncondensing
