Cisco Catalyst 3750-X Command Reference

2-65
Catalyst 3750-X and 3560-X Switch Command Reference
OL-29704-01
Chapter 2 Catalyst 3750-X and 3560-X Switch Cisco IOS Commands
auto qos voip
Command Modes Interface configuration
Command History
Usage Guidelines Use this command to configure the QoS appropriate for VoIP traffic within the QoS domain. The QoS
domain includes the switch, the network interior, and edge devices that can classify incoming traffic for
QoS.
Auto-QoS configures the switch for VoIP with Cisco IP Phones on switch and routed ports and for VoIP
with devices running the Cisco SoftPhone application. These releases support only Cisco IP SoftPhone
Version 1.3(3) or later. Connected devices must use Cisco Call Manager Version 4 or later.
To take advantage of the auto-QoS defaults, you should enable auto-QoS before you configure other QoS
commands. You can fine-tune the auto-QoS configuration after you enable auto-QoS.
Note The switch applies the auto-QoS-generated commands as if the commands were entered from the
command-line interface (CLI). An existing user configuration can cause the application of the generated
commands to fail or to be overridden by the generated commands. These actions occur without warning.
If all the generated commands are successfully applied, any user-entered configuration that was not
overridden remains in the running configuration. Any user-entered configuration that was overridden can
be retrieved by reloading the switch without saving the current configuration to memory. If the generated
commands fail to be applied, the previous running configuration is restored.
Table 2-10 Auto-QoS Configuration for the Ingress Queues
Ingress Queue Queue Number CoS-to-Queue Map
Queue Weight
(Bandwidth)
Queue (Buffer)
Size
SRR
1
shared
1. SRR = shaped round robin. Ingress queues support shared mode only.
1 0, 1, 2, 3, 6, 7 70 percent 90 percent
Priority 2 4, 5 30 percent 10 percent
Table 2-11 Auto-QoS Configuration for the Egress Queues
Egress Queue Queue Number CoS-to-Queue Map
Queue Weight
(Bandwidth)
Queue (Buffer) Size
for Gigabit-Capable
Ports
Queue (Buffer)
Size for 10/100
Ethernet Ports
Priority (shaped) 1 4, 5 up to 100 percent 25 percent 15 percent
SRR shared 2 2, 3, 6, 7 10 percent 25 percent 25 percent
SRR shared 3 0 60 percent 25 percent 40 percent
SRR shared 4 1 20 percent 25 percent 20 percent
Release Modification
12.2(53)SE2 This command was introduced.
12.2(55)SE Support for enhanced auto-QoS was added.

Cisco Catalyst 3750-X Specifications

General

Switching Capacity	160 Gbps
Stacking Bandwidth	64 Gbps
Max Stacking Units	9
Layer Support	Layer 2 and Layer 3
Form Factor	Rack-mountable
DRAM	256 MB
Flash Memory	64 MB
Model	Cisco Catalyst 3750-X Series
Ports	24 or 48 10/100/1000 Ethernet ports
Uplink Interfaces	4 SFP or 2 SFP+
Features	StackWise Plus, EnergyWise
Image	IP Base or IP Services
Operating Temperature	0 to 40°C
Operating Humidity	10 to 85% noncondensing
