v2.13 Cleverscope CS300 Reference Manual
©Cleverscope 2004-2018 www.cleverscope.com Page 123
18.2 Using the Signal Generator Simulator
The Signal Generator Simulator is connected to Channels A and B internally.
On the Cleverscope control panel.
Click on the Settings menu.
Click on Choose Acquirer and set connection menu option.
In the Choose Acquirer and set connection window click on Type of Acquirer and then
Click Simulated Sig Gen and Click OK.
Click Auto in the ACQUIRE panel of the Cleverscope controls.
You should see signals appear on both channels if both A and B are Enabled ON.
Adjust the Signal Generator Simulator controls as required.
