Hi/Lo, MSB first or not, Number of stop bits.
Naming label. Character, Hexadecimal or Decimal Number. Colour.
28.14 Charting
1 Sample per Second – 1.5 Mega Samples Per Second (Can be increased
to
Peak capture or Moving average filter prior to decimation. Using 1.28us
filter with 12 or 14 bit ADC we achieve 16 bits ENOB at 1 MSPS.
Up to 500 G samples. Samples are stored in multiple smaller files to
increase speed.
Zoom and pan anywhere in sample space. Samples are displayed peak
captured (i.e. 1us pulse will still be visible in 1 day long sample record).
Export tab delimited text, binary, or Cleverscope format file. Output
between markers, or current display. Set output depth.
28.15 Data Export
Cleverscope proprietary, Tab delimited text (Excel compatible), Excel file
(for signal information logging).
DDE to Excel, direct placement of data into live Excel sheet
Live data output to and return from Matlab
28.16 Windows Facilities
Copy and Paste
Save and Open native format (saves full setup)
Save and Open tab delimited text file
Save and Open binary file (start time, dt, data)
Print with Date/Time, File Name and Description.
Print Setup
Dynamically resized
Can be placed anywhere on desktop
User settable signal names
Scale + offset by defining two (Vin, Vout) points
Signals, Background, Major Grid, Minor Grid
28.17 Probe Compensator Output
28.18 Power Source
Standard power adaptor
voltage range
28.19 Environmental
Operating: 0C to +40C
Storage: -20C to +60C
