Cleverscope CS300 - PC Interface; Calibration; Displays

v2.13 Cleverscope CS300 Reference Manual
©Cleverscope 2004-2018 www.cleverscope.com Page 181
Automated measurements
DC component
RMS value
Maximum voltage
Minimum Voltage
Peak-Peak
Standard deviation
Period
Fundamental Signal Frequency
Fundamental Signal Amplitude
Pulse width
Duty Cycle
Freq and Amplitude for fundamental + second and third harmonics
THD
SINAD
HD2+3
Custom units
6 characters
Custom signal names
20 characters
Custom scaling
Scale + offset by defining two (Vin, Vout) points
User definable colours
Signals, Background, Major Grid, Minor Grid
28.8 PC Interface
USB Interface
USB 2.0 (480 Mbit/sec)
Effective Throughput rate
18 Mbyte/sec
Isolation
None
Ethernet Interface
Ethernet (100 Mbit/sec)
Effective Throughput rate
6 Mbyte/sec
Isolation
20 pF, 1500VAC isolation
Ethernet connectivity
DHCP or Point-to-Point or IP addresses. Cable direction auto-sense.
28.9 Calibration
Calibration method
Automatic self-calibration
Calibration Voltage Source
Range 2.5V
Resolution 1 mV
Drift 11 ppm/C
Accuracy 1%
Temperature Compensation
Via Internal temperature sensor, 1.5C accuracy
28.10 Displays
Windows
Simultaneous Capture, Tracking, Spectrum, Information, Maths, XY,
Control Panel and Protocol setup windows
Scope Display (Capture)
Defines capture specification for signal acquisition unit, defining amount
of time before trigger, amount of time after the trigger, lower amplitude
limit, upper amplitude limit.
Defines tracking graph time position, when displays are linked.
Defines trigger level and direction
Full zoom and Pan in both axis.
Annotations.
Custom colours
Tracking Display
Displays zoomed section of captured signal. Resolution from 10ns to
5s/div.
