Cleverscope CS300 Reference Manual v2.11
Page 184 www.cleverscope.com ©Cleverscope 2004-2015
Cooling Method
Convection
Humidity
0C to +40C <90% relative humidity
>40C <60% relative humidity
Altitude
Operating 3,000 m
Non-operating 15,000m
28.20 Mechanical
Size
Height 35 mm
Width 153 mm
Depth 195 mm (including BNC)
Weight (approx.)
Standard packaging: 1.6 kg
28.21 Expansion Capability - Signal Generator Module CS700A
Function
Generate Sine, Square or Triangle output signals
Generation Method
Direct Digital Synthesis
Output Sampling Rate
50 MSamples/sec
Frequency Range
Sine, Square: 0.2 Hz – 10 MHz
Triangle: 0.2 – 1 MHz
Resolution
0.003 (<750 kHz) or 0.2 (<10 MHz) Hz
Accuracy
50 ppm in 1 year, 0-40 deg C
Output Voltage Range
300mV – 5V p-p including DC offset
Output Voltage Resolution
10 mV
Output Impedance
50 ohm
Output Voltage Offset Range
-4 to +4V
Output Voltage Offset
Resolution
10 mV
Frequency Shift Range
Any two frequencies in range 0.2Hz – 10 MHz
Signal to Noise Ratio
-60 dBc typical
Total Harmonic Distortion
0 – 1 MHz : < -60 dBc
> 1 MHz: < -45 dBc
Amplitude Flatness
± 0.2 dB
Amplitude Accuracy
± 2%
Square Wave Rise/Fall Times
< 12 ns
Protection
Short Circuit Protected
± 10V peak overdrive < 1 min
28.22 Expansion Capability – Increase Sampling Channels and Sample Rate
4 analog, and 16 digital
channels
Connect two units together with Trigger Link Cable (CS20xx)
Uses two computer USB ports
Increase in sampling rate to
200MSPS
Uses 5ns delay line (CS@XXX), and the Maths ‘Interleave’ function
