v2.13 Cleverscope CS300 Reference Manual
©Cleverscope 2004-2018 www.cleverscope.com Page 163
Some defects:
1. You cannot use the trigger cursors to set the trigger for Unit 2 (Channels C and D). You will need to
type in the trigger level directly.
2. If you run the application with only one acquisition unit connected, it will turn off the other two
channels, and they won’t be used. However the tabs will stay visible. After exiting, you might connect
the other unit. When you start up the Cleverscope4 application, and run an acquisition, it will see that
last time there were only two channels, and will not display the tabs, even though there are 4 channels.
You need to exit the application and the start it again. The tabs for both units will be present; however
the channels for unit 2 will be disabled. On the acquire tab, click Unit 2, and then enable both channels
(if you want them).
3. There are still some situations where things get confused. We have to work on this. The easiest way out
is to quit the application, cycle the power on both units, and start again.
All the same, it seems to be working well enough to demonstrate the concept. We will be improving it.
