User's Manual
172
●
Device supports maximum 100 view groups.
●
The views hierarchy shall not be more than 2. For example, after you create View Group 1 under
View, you can create a sub-level View Group 2 under View Group 1. However, you cannot create
sub-level group under View Group 2.
7.1.1.1.1 Creating View Group
Step 1 Follow the steps listed below to create a view group.
●
Click
View Group or a created view group, and then click .
●
Right-click
View Group or a created view group, and then select Add View Group.
System creates one view group.
Figure 7-4 Create view group
Step 2 Set view group name.
●
The view group name ranges from 1 to 64 characters. It can contain English letters,
numbers and special characters.
●
View group is to classify or category different view groups. We recommend the view
group name shall be easy to recognize.
Step 3 Click any black space on the page.
7.1.1.1.2 Operation
After creating view group, view group can be renamed or deleted.
