User's Manual
244
System pops up a confirmation box.
Step 4 Click
OK.
The binding card information becomes activated after reboot operation.
8.3.1.2.2 Cancelling Binding NIC
Cancel port aggregation and allow the bonded NICs to work as independent card.
Step 1 Click or click on the configuration page, and then select
NETWORK > Basic
Network > TCP/IP.
Step 2 Select a bonded NIC.
Step 3 Click OK.
System splits the bonded NIC.
After splitting NIC binding, the first NIC reserves the IP address configured during binding,
while the rest NICs restore default IP addresses.
8.3.1.3 Setting Port Number
Set device port number.
Step 1 Click , or click on the configuration page, and then select NETWORK > Basic
Network > Port.
Figure 8-24 Port
Step 2 Set parameters.
Log in again after modifying parameters except Max Connection.
Table 8-9 Connection setting parameters description
Max Connection
The allowable maximum clients accessing the Device at the same
time, such as web, PCAPP, and Platform. Select a value between 1 and
128. The default value setting is 20.
